The G80 Swivel Hoist Ring Side Loading Lifting Point is a threaded lifting attachment for loads that require angular or lateral lifting. Its 360° rotating body and pivoting load ring allow the sling connection to align with the lifting direction. Unlike a fixed lifting eye, it accommodates changing sling angles within the product's rated working limits.
Key Specifications
|
Parameter |
Specification |
|
Product Type |
G80 Swivel Hoist Ring |
|
Application |
Side and angular lifting |
|
Load Ring Movement |
Pivoting to align with the lifting direction |
|
Body Rotation |
360° |
|
Mounting |
Threaded bolt |
|
Bolt Finish |
Black oxide |
|
Alternative Finish |
Zinc plating |
|
Bolt Length |
Available in different lengths |
|
Assembly |
Removable body-and-bolt design |
Confirm the model-specific WLL, thread size, bolt dimensions, safety factor and permitted loading angles before ordering.
Product Advantages
Flexible Load Alignment: The 360° rotating body and pivoting load ring allow the attachment to follow changing sling directions, helping accommodate angular lifting within the rated limits.
Secure Threaded Mounting: The threaded bolt fastens the lifting point to a compatible mounting hole, providing a stable attachment for lifting machinery, molds and heavy components.
Easy Disassembly: The removable bolt-and-body design allows the components to be separated for maintenance or replacement, simplifying servicing when required.
Compatibility
Threaded Mounting: Designed for installation in a compatible threaded hole on machinery, molds and heavy components.
Angled Lifting: The 360° rotating body and pivoting load ring accommodate changing sling directions within the rated loading limits.
Mounting Configuration: Different bolt lengths are available to suit mounting requirements, subject to model specifications.
Surface Finish: Black oxide is the standard finish; zinc plating is available as an alternative.
Load Capacity: The applicable WLL depends on the specific model and loading angle. Confirmed model-specific ratings are required before selection.
Applications
Mold Handling: Installing and removing injection molds and die sets from molding machines and storage racks.
CNC Machinery: Lifting machine beds, spindle assemblies and heavy components during installation or maintenance.
Steel Fabrication: Positioning welded frames, steel plates and fabricated assemblies during production.
Equipment Maintenance: Removing and reinstalling gearboxes, housings and other heavy machine components.
Quality Control
Dimensional Inspection: Thread gauges verify bolt thread size and fit, while calipers check critical dimensions against approved drawings. Results are recorded against specified tolerances.
Material Verification: Material certificates and applicable material tests verify conformity with the specified steel grade.
Proof Load Testing: The assembled lifting point is subjected to the specified proof load. The result is assessed against the applicable acceptance criteria, including permanent deformation and structural damage.
Final Inspection: Inspectors check thread condition, surface finish, component assembly and product markings before release. Nonconforming products are held for disposition.
Customization Options
Bolt Length: Different lengths to match mounting depth.
Thread Type: Metric or UNC threads.
Surface Finish: Black oxide or zinc plating.
Thread Size: Available sizes according to the product model.
Supply Information
Minimum Order Quantity: 1 piece for standard models; custom orders subject to confirmation.
Lead Time: Approximately 10–15 working days for standard orders, subject to stock and order quantity.
Packaging: Individual product packaging with applicable instructions, followed by export cartons.
Bulk Orders: Production schedules and shipment arrangements confirmed according to order quantity.
Technical Documents: Product drawings, inspection records and material certificates available subject to model and order requirements.
Shipping: Export shipment by sea, air or express courier, depending on order volume and destination.
Maintenance & Inspection
Thread Care: Clean threads after use and check for wear, deformation or damage.
Moving Parts: Check swivel and pivot movement for stiffness, abnormal play or jamming.
Surface Condition: Inspect for cracks, corrosion and visible damage before each lift.
Lubrication: Lubricate moving parts as specified in the manufacturer's instructions.
Replacement: Remove the lifting point from service if defects are found; do not reuse until approved.
FAQ
Q: How is the WLL of a G80 Swivel Hoist Ring determined?
A: The WLL depends on the specific model and permitted loading angle. The applicable rated capacity must be established from the manufacturer's load data for the intended configuration.
Q: Can a G80 Swivel Hoist Ring replace a standard lifting eye bolt?
A: Not as a direct substitute in every application. The mounting thread, load-bearing capacity, available clearance and permitted loading directions must match the equipment and lifting plan.
Q: Are G80 Swivel Hoist Rings available from stock?
A: Stock availability depends on the model and quantity required. Standard models may be available for faster dispatch, while larger or non-standard orders may require production lead time.
Q: Can G80 Swivel Hoist Rings be purchased for OEM equipment production?
A: Yes, where the required model and configuration are within the supplier's manufacturing capabilities. Buyers should provide the equipment drawing, installation dimensions, required quantity and applicable technical specifications for confirmation.
Q: What technical documents should be requested when purchasing swivel hoist rings?
A: Depending on project requirements, buyers may request product drawings, rated-load documentation, material certificates, proof-load test records and inspection reports. Availability should be confirmed before placing the order.
Q: What is the typical service life of a G80 Swivel Hoist Ring?
A: Service life depends on lifting frequency, load conditions, operating environment and inspection results. There is no universal service-life period applicable to every installation.
Q: Can G80 Swivel Hoist Rings be supplied with product identification markings?
A: Product markings depend on the model and manufacturing specifications. Required identification details should be confirmed with the supplier before ordering.
